PAD COMMAND || CATIA V5 Tutorial || Part Design

Part Modeling - TOOLBAR - SKETCH-BASED FEATURES COMMAND - PAD USE - PAD command use for 'Material Addition'. Here I explained each and every concept in detail. A) PAD - First Limit & Second Limit 1. Types - Dimension (length or limit) Up to Next Up to Last Up to Plane Up to Surface 2. Thick 3. Mirror Extent - 4. Direction (Reference Selection) 5. Thin Pad 6. Neutral Fiber 7. Merge Ends B) Drafted Filleted Pad First Limit & Second Limit Draft (Angle) Fillets (Radius) C) Multi - Pad First Limit & Second Limit Type length Direction (Reference Selection)

To be continued ...
